The map contains the 225km 24″ Chayvo – De-Kastri Oil Pipeline, which runs from Sakhalin-I project’s Chayvo Onshore Processing Facility (OPF) in Noglikskiy, Sakhalin, and sends the crude oil to De-Kastri Oil Export Terminal in Ul’chskiy, Khabarovsk.
Table of Descriptions
1 Product Details
张开剩余80%2 Files Included in This Digital Map
3 Editability of Map
4 Related Upstream/Downstream Pipelines
1 Product Details
Product Name: Map of Chayvo – De-Kastri Oil Pipeline Название Продукта: Карта Чайво – Де-Кастри магистральный нефтепровод Product Type: Vector Map Pipeline Length: 225km Country: Russia From: Noglikskiy, Sakhalin To: Ul’chskiy, Khabarovsk No. of Onshore Processing Facility, Oil Export Terminal: 2 No. of Block Valve Station: 8 Coordinate Data: Not Available File Formats: Adobe PDF, Adobe Illustrator Lifetime Updates: Supported Language: EnglishNote: This digital map is NOT a GIS map or don’t contain coordinate data.
2 Files Included in This Digital Map
[Main Map] Chayvo – De-Kastri Oil Pipeline
This map includes the geographical area from the pipeline’s starting point to its end point. Its content contains the pipeline route, stations along the pipeline, and the administrative regions that the pipeline passes through.
Two file formats, .pdf and .ai (Adobe Illustrator), are included. Both of them are editable and layered. Users can show and hide a layer simply with a mouse click.
The map consists of following independent layers:
Project Name and Legend Names of Main Stations Names of Block Valve Stations Names of Water Names of Federal Subjects Names of Districts Main Stations Block Valve Stations Pipeline Water Borders of Federal Subjects Borders of Districts Background Color3 Editability of Map:
Based on the layered digital map (.pdf and .ai), users can perform further development and modifications云开体育, including but not limited to:
Adjusting the position of text and modifying its attributes such as font, font size, and color; Adjusting the position and size of icon symbols; Modifying the path of oil and gas pipelines to reflect changes caused by rerouting; Adding new pipelines and stations; Changing the border color and line weight of different administrative regions; Modifying the map background color.发布于：上海市
